This is the 22 Magnum, an original design inspired by both PRS and Gibson guitars.

I call this particular build “Rootbeer Float”

Materials:

  • Body and neck wood – “Honduran” mahogany (swietenia macrophylla)
  • Top wood – Quilted big leaf maple, book matched. Matching headstock overlay.
  • Fretboard wood – variegated Brazilian rosewood (dalbergia nigra) with sap and heart woods.
  • Truss rod cover – Gaboon ebony (Diospyros crassiflora) with white MOP inlay
  • Fret wire – Stainless steel
  • Fretboard inlays – white mother-of-pearl and abalone
  • Nut – Unbleached bone
  • Control cavity cover – Indian rosewood with magnetic attachment
  • Finish – Nitrocellulose lacquer

Specs:

  • Construction – neck-through-body w/ 3-piece neck laminate and carbon fiber reinforcement
  • Overall length – 39″
  • Scale length – 25″
  • Fretboard radius – 12″
  •  Number of frets – 22
  • Weight – 8 lbs. on the nose

Hardware:

  • Pickups – Seymour Duncan JB (bridge) and 59′ (neck) with polished nickel covers
  • Tuners – Schaller scrome locking 3×3
  • Bridge and tailpiece – Chrome Tonepros “System II” locking
  • Volume and tone pots – CTS 500k
  • Switch – switchcraft 3-way toggle





This is the block of maple the top will be cut from. Its freakin spectacular! To the right of the wenge are 6 boards of genuine Bolivian mahogany (Swietenia macrophylla), 3 of those board will be used in this build Bridge and pickup covers. These will cover Seymour Duncan JB and 59. Heres those same covers after being soldered to a JB and a 59   An array of templates I’ll use for the build. I designed them in CAD, and a business associate in Sydney Australia cut them for me on a CNC machine.   Brazilian rosewood fretboard blank with my bird inlays laid out on it.   Go to the Build

Root beer float
